1)The medical surgical film produced in our company is the lasted
generation product among nowadays surgical operation films. It
consists of waterborne PU film, release paper, medical pressure
sensitive adhesive, ect.
The material waterborne PU film, is produced by new technology. Its
performance index has reached international advanced level. It is
our patented material.
2) The product is soft, light and skin-friendly, and is featured by
high elasticity, breathe freely, waterproof, moderate stickiness
and free from fall off in operation.
It can prevent disinfection from infection and keep the wound from
water, bacteria and dirt;
the operation area can be clearly seen before operation, so the
operating scalpel could be cut on the transparent film, in order to
eliminate the un-killed bacteria within the pores and other places
and effectively curb the bacteria from moving in operation;
the protection area may prevent cross-infection; and through this
method will not bring skin irritation after operation, and will not
leave glue when peeling, so time for clearing and four towels and
other dressing can be saved.
Technical details ofself adhesive surgery pe film:
Material: Water-based PU breathable film
Thickness 25-30 micron and 35-50 micro; - barrier for fluids and microorganisms; - no plasticizer or components leaching in water or oil; - water vapor can penetrate but fluid cannot passed; - elongation > 300%, Good Flexibility - melting temperature > 150C; - paper or PET release liner, can do based on customer’s
requirement. - White or translucent matte, possible to have the film colored - maximum 1000 mm wide roll, 1000m long per roll
Specification ofself adhesive surgery pe film:
No.
Technical specification
Index
1
Tensile strength
lengthways 8.0Mpa
crosswise 7.8Mpa
2
Elongation at break
lengthways 321%
crosswise 347%
3
Tear strength
lengthways 20.0kN/m
crosswise 19.8kN/m
4
Impact resistance
No broken when testing
5
Haze
10.30%
6
Glossiness
76.60%
7
Friction coefficient
Dynamical friction 0.284
Static friction 0.158
8
Water Vapor Permeance
1562g/(m2*24h*0.1Mpa)
9
Oxygen permeability
>38mN/m
Size available for choice:
Type
Specification
Scope of Application
Sheet Number/Box
Small Box Number/Box
Ordinary Type
20*30
It is applicable to skin protection for operation area before
surgical operation.
